Super Artery EXCEEDS ISO18752-AC/BC/CC -Letone

Parameter

model	ISO18752			Inner diameter of hose （mm)	Outer diameter of hose （mm)	Working pressure （MPa)	Minimum burst pressure （MPa)	Minimum bending radius （mm)	Weight （kg/m)	Connector series
model	6992standard tube	6992 wear-resistant tube AARR	6992 super wear-resistant tube	Inner diameter of hose （mm)	Outer diameter of hose （mm)	Working pressure （MPa)	Minimum burst pressure （MPa)	Minimum bending radius （mm)	Weight （kg/m)	Connector series
SA6992-1/4"-1	AC	AC	AC	6.3	13.4	25	100	40	0.219	31series
SA6992-5/16"-1	AC	AC	AC	8.0	15.2	25	100	55	0.277	31series
SA6992-3/8"-1	AC	AC	AC	10.0	17.4	21	84	65	0.33	31series
SA6992-1/2"-4	AC	AC	AC	13.0	22.2	25	100	110	0.658	31series
SA6992-5/8"-4	AC	AC	AC	16.0	24.0	25	100	130	0.771	31series
SA6992-3/4"-4	BC	CC	CC	19.0	28.2	25	100	160	0.939	31series
SA6992-1"-4	BC	CC	CC	25.0	35.3	21	84	210	1.247	31series
SA6992-1 1/4"-4	CC	CC	CC	32.0	44.0	21	84	250	1.874	31series
SA6992-1 1/2"-4	CC	CC	CC	38.0	49.5	18	72	300	2.127	31series
SA6992-2"-4	CC	CC	CC	51.0	63.0	18	72	610	2.848	31series

无标题文档

Product Description

Note style

Product Features

Low bend：The average minimum bending radius of the entire series of hoses is 34% lower than the ISO18752 Class C standard (Note: The Class C standard refers to the compact category in the ISO18752 standard), which is easy to install and save equipment space；

High pressure：All pressures meet/exceed ISO18752 AC/BC/CC/DC standards；

Life：Powerful pulse performance, the pulse times of the entire series of hoses are more than 1 million times, which greatly extends the service life of the hose。

Comparison of Super Hercules Low Bend Series Hose and ISO18752 Standard Parameters
grade	ISO18752 standard temperature	ISO18752 standard impulse pressure	ISO18752 standard minimum pulse	super Hercules minimum pulse
AC	100℃（212℉）	133%	200,000 times	1 million times
BC	100℃（212℉）	133%	500,000 times	1 million times
CC	120℃（250℉）	133%	500,000 times	1 million times
DC	120℃（250℉）	133%	1 million times	1 million times

Model Selection

The convenience of the Super Hercules low bending series is mainly reflected in three aspects：

1、There is obvious pressure classification, easy to find the model；

Super Hercules Low Bend Series Hose Pressure Selection Table
Inner diameter of hose Hose model	1/4”	5/16”	3/8”	1/2”	5/8”	3/4”	1”	1 1/4”	1 1/2”	2”
LTSA6991	—	—	—	18	15	14	14	14	9	8
LTSA6992	25	25	25	—	25	25	21	21	17.5	17.5
LTSA5991	—	—	—	28	28	28	28	28	28	28
LTSA5992	40	35	35	35	35	35	35	35	35	35
LTSA5993	45	45	45	45	42	42	42	42	42	42

2、Only need to select the corresponding model from the three connector series; Note：31 is hose connector 31 series; 41 is hose connector 41 series; 61 is hose connector 61 series。

Super Hercules Low Bend Series Connector Series Selection Table
Inner diameter of hose Hose model	1/4”	5/16”	3/8”	1/2”	5/8”	3/4”	1”	1 1/4”	1 1/2”	2”
LTSA6991	—	—	—	31	31	31	31	31	31	31
LTSA6992	31	31	31	—	31	31	31	31	31	31
LTSA5991	—	—	—	31	31	41	41	41	41	41
LTSA5992	31	31	31	41	41	41	41	41	61	61
LTSA5993	41	41	41	41	41	41	41	61	61	61

3、Adopt one-piece non-stripping glue joints (31 and 41 series) and split joints (61 series)） Note: The integrated non-stripping glue and split joints are matched with Litong self-developed hydrogenated nitrile seals, which is infinitely close to the sealing goal of zero leakage.。

One-piece non-stripping glue joint (31 and 41 series)

1)Eliminates hose crimping problems caused by stripped or too short hoses；
2)Save manpower, easy to operate；
3)One connector is suitable for multiple hoses；
4)Clean and beautiful after crimping。

Split connector (61 series)

1)More flexibility, more choices of joints and sleeves；
2)Joints and sleeves can be purchased separately according to existing inventory。

Customized Outer Layer Of Hose

Based on EN853: 2015, the outer layer of the Super Hercules low bending hose series is reciprocated at a frequency of 1.25HZ under 25N gravity according to the method specified in the GB/T 12721-2007/ ISO6945: 1991 inspection standard. In the abrasion test, the quality loss of the outer layer material under 2000 cycles is compared, and the outer layer of the Super Hercules low-bending hose is divided into the following three types：

Standard outer layer：Oil-resistant, abrasion-resistant and weather-resistant synthetic rubber；
Abrasion Resistance (AR) outer layer：The wear-resistant quality loss is 1/7 of that of the standard tube outer layer, that is, its wear resistance coefficient is 7 times that of the standard outer layer. Wear-resistant AR outer hose is suitable for relatively harsh environment；
Super abrasion resistance SAR (Super >Abrasion Resistance>) outer layer：Using UHMWPE outer layer, the quality loss of outer layer material under 2000 cycles is 0. Super wear-resistant SAR outer hose is suitable for extremely harsh environment。

Certified Product

LT SA5993

Super Artery EXCEEDS ISO18752 DC

Inner rubber layer：Neoprene synthetic rubber, suitable for hydraulic oil that can be degraded
Reinforcement：Four layers of steel wire winding (1/4"‒1"), pulse ≥1 million, six layers of steel wire winding (1 1/4"‒2"), pulse ≥1 million times
Outer layer：non-stripping, wear-resistant, weather-resistant synthetic rubber
Temperature range：-40°C to +121°C (-40°F to +250°F)
Low bending：the bending radius is reduced by 27% compared with the ISO18752 standard; it is reduced by 37% compared with the SAE standard
High pressure：pressure conforms to ISO18752 DC standard

Inquiry

LTSA699

Super Artery wire braided hose

Tube：CR/NBR synthetic rubber
Reinforcement：braided high tensile super fexible steel wire, one braid impulse reaches 300,000 cycles, two braids reaches 600,000 cycles
OuterLayer：Black glossy anti-aging and non-peeling synthetic rubber layer
Low bending radius：30% lower than SAE/DIN standards
High pressure：25% higher than SAE/DIN standards
Long service life：weather resistant for more than 5 years and warrantied for 2years (with Letone specific hoseconnectors)

Inquiry

LTSA599-FH

Super Artery super soft hose

Inner Layer：Oil resistant synthetic rubber
Reinforcement：4-layered high-strength super-flexible steel wire
Outer Layer：Wear-resistant, weather-resistant synthetic rubber (weather-resistant for 5 years, warranty for 3 years)
Characteristic：Low bending-bending radius is 50% lower than DIN EN853 standard; high-pressure-pressure is 30%~40% higher than DIN EN853 standard; long life.
Hose Fitting：It adopts high-quality carbon structural steel, the core material is 45# steel, the nut material is 35# steel, and the sleeve is 20# steel, which conforms to the national, British and American national standards. The joint sealing is made of hydrogenated nitrile rubber (10 years of aging resistance) Above) Use the one-piece hose connector specially provided by Litong, with pulse >= 1 million times.
Temperature Range：-40℃~+85℃(-40℉~+185℉)H

Inquiry

LT SA6991

Super Artery EXCEEDS ISO18752-BC/CC

Inner rubber layer：Nitrile or neoprene synthetic rubber, suitable for biodegradable hydraulic oil
Reinforcement layer：one or two layers of steel wire weaving (1/2" ‒3/4"), pulse ≥ 300,000 times, four layers of steel wire winding (1" ‒ 2"), pulse ≥ 1 million times
Outer layer：non -stripping, wear-resistant, weather-resistant synthetic rubber
Temperature range：-40℃ to +100℃ (-40℉ to +212℉) -40℃ to +121℃ (-40℉ to +250℉)
Low bending：the bending radius is reduced by 41% compared to the ISO18752 standard; 47% lower than the SAE standard
High pressure：exceed the SAE standard by 60%
